Extend Your Range. Explore What's Possible.
Marking a historic milestone as the first 7-string model in PRS's core American-made bolt-on catalog, the PRS Tekton SVN is purpose-built for extended-range musicians. Featuring an optimized 26.5” scale length, the Tekton SVN maintains ideal low-B string tension and crisp note clarity for drop-tuned riffing without compromising high-register bending comfort.
This one features a vibrant Fuchsia Aura translucent coat designed to command attention on stage while providing tight low-B string tension.
The figured mango top and lightweight mahogany body feature sculpted contours and an exaggerated lower cutaway for effortless access to all 24 stainless steel frets. Voiced specifically for extended frequencies, the custom PRS Stylus SVN humbuckers deliver articulate, aggressive, and highly defined tone across all 7 strings, preventing low-end mud in complex chords or high-gain recording scenarios.
Sanctuary Expert Profile
Best For: Modern Metal, Extended Range Fusion, Prog, and Low-Tuned Studio Work.
Tone Profile: Deep, focused, and aggressive with tight low-end tracking and clear harmonic articulation across all frequencies.
Technical Specifications
- Top Wood: Figured Mango (Shallow Violin Carve)
- Back Wood: Solid Mahogany
- Neck Wood: Maple (Scarfed Construction with Hormigo Rods)
- Neck Profile: Modern "D" SVN (1 29/32" Nut Width)
- Fretboard: Ebony with 16" Radius & Blue Luminlay Side Dots
- Frets: 24 PRS Jumbo Stainless Steel
- Scale Length: 26.5"
- Bridge: PRS 7-String Hardtail (String-Through)
- Tuners: PRS Phase III Locking Tuners
- Pickups: PRS Stylus SVN Treble & Bass Pickups
- Controls: Volume, Push/Pull Tone Control with 3-Way Blade Switch
- Hardware: Smoked Black
- Case: Premium PRS Heavy-Duty Gig Bag Included
Stock Photos Shown, Individual Color and Grain will vary from guitar to guitar.
BODY
Body Construction: Solidbody
Top Wood: Figured Mango
Back Wood: Mahogany
Top Carve: Shallow Violin
NECK
Number of Frets: 24
Fret Wire: PRS Jumbo
Fret Wire Material: Stainless Steel
Width of Fret Crown: .110”
Height of Fret Crown: .055”
Scale Length: 26.5”
Neck Wood: Maple
Neck Construction: Scarfed
Truss Rod: PRS Double-Acting
Neck Shape: Modern “D” SVN
Neck Depth at the 1/2 Fret: 49/64”
Neck Depth at the 12 1/2 Fret: 27/32”
Neck Width at the Nut: 1 29/32”
Neck Width at the Body: 2 5/8”
Fretboard Wood: Ebony
Fretboard Radius: 16”
Sidedots: Luminlay, Blue
Fretboard Inlay: Offset Dots
Headstock Logo: Signature, Inlaid
NECK/BODY ASSEMBLY
NBA Type: Bolt-On
FINISH
Finish Type: High-Gloss Nitro
Neck Finish Type: Satin Nitro
HARDWARE
Bridge: PRS Hardtail, 7-string
Tuners: PRS Phase III Locking Tuners
Hardware Type: Smoked Black
Nut: PRS
Truss Rod Cover: Tekton
ELECTRONICS
Treble Pickup: PRS Stylus SVN
Bass Pickup: PRS Stylus SVN
Controls: Volume and Push/Pull Tone Control with 3-way Blade Pickup Switch
ADDITIONAL INFORMATION
Factory Strings: PRS Signature, 10-59
Factory Tuning Standard (7-String): B, E, A, D, G, B, E
Included Accessories: PRS Premium Gig Bag
