The Sanctuary Tone Profile & Technical Specs
The industry standard has evolved. The CIOKS DC7 V2 marks the next generation of the world's thinnest, most flexible pedalboard power supply. Retaining the legendary 1-inch low profile that made the original 2018 release a staple for touring rigs, the V2 architecture has been thoroughly optimized to run more efficiently and significantly cooler under heavy loads. Crucially, the outdated USB-A port has been replaced with a high-current 15W USB-C outlet—delivering three times the charging capability of its predecessor. Powered by an advanced two-stage switch-mode topology, the DC7 V2 pushes up to 48W across 7 isolated DC outlets and a 24V DC link, delivering zero-noise power capable of handling power-hungry modelers and multi-effects setups with ease.
What Comes in the Box:
- CIOKS DC7 v2 power supply
- Mains power cord
- Standard Flex type 1 – black with 5,5/2,1mm centre negative DC plug x7
- Standard Flex type 2 – red with 5,5/2,1mm centre positive DC plug x1
- Standard Flex type 4 – green with 5,5/2,5mm centre positive DC plug x1
- Standard Flex type 5 – black with tip positive 3,5mm Jack plug x1
- Split Flex type 1 – powers two pedals of a single outlet x1
- 3-way Daisy chain Flex type 1 – powers three pedals of a single outlet x1
- Mounting hardware: 2 screws and a hex-key
- Manual
- Product sheet (drill guide)
- CIOKS sticker sheet
- Flex guide
Groundbreaking 1-inch profile (25,4mm)
2-stage switch-mode power supply topology
Ultra-low noise achieved by multistage filtering
7 isolated DC-outlets, 6W each 660mA at 9V DC on each outlet
4 selectable voltages on each outlet
5V USB outlet with max.
3A 24V DC auxiliary outlet with max. 2A
Individual power limit LED on all outputs
Built-in true power meter showing the total load
Global overload status LED
Universal mains input voltage 90 to 265V AC
Total maximum output power 48W
Mounting hardware for Pedaltrain and Templeaudio boards included
Compatible with CIOKS GRIP for drill-free mounting on Pedaltrain boards*
12 Flex cables included
Expandable with CIOKS 4*, CIOKS 8* and Crux*
Weighs 1.1 lbs. (500 grams)
Designed in Denmark, assembled in Poland
Mains input: 90-265V AC universal
Outlet 1-7: 9V DC / 660mA or 12V DC / 500mA or 15V DC / 400mA or 18V DC / 330mA each
USB outlet: 5V DC, max 3A
AUX outlet: 24V DC, max 2A
Total maximum output power: 48W
Size: 160 x 88 x 25,4mm excl. rubber feet
Weight: 500g / 1.1lbs
Warranty: 5 years worldwide
